Thermaltake PC- Netzteil TOUGHPOWER PF1 750W Platinum |PS-TPD-0750FNFAPE-1
Accedi in modo che possiamo avvisarti di una risposta
Descrizione
Thermaltake Toughpower PF1. Total power 850 W, AC input voltage 100 - 240 V, Peak power 900 W. Motherboard power connector 24-pin ATX, Motherboard power cable length 60 cm, SATA power cable length 150,500 mm. Power supply unit (PSU) form factor ATX, 80 PLUS certification 80 PLUS Platinum, Noise level 27.8 dB. Product colour Black, Fan diameter 12 cm, Number of fans 1 fan(s). Width 150 mm, Depth 140 mm, Height 86 mm
Power Total power 850 W Peak power 900 W AC input voltage 100 - 240 V AC input frequency 50/60 Hz Input current 10 A Power Factor Correction (PFC) type Active Combined power (+3.3V) 100 W Combined power (+12V) 744 W Combined power (-12V) 3.6 W Combined power (+5Vsb) 12.5 W Max output current (+3.3V) 20 A Max output current (+12V) 62 A Max output current (+5V) 20 A Max output current (-12V) 0.3 A Max output current (+5Vsb) 2.5 A Hold time 16 ms Power protection features Over current, Over voltage Performance Power supply unit (PSU) form factor ATX 80 PLUS certification 80 PLUS Platinum Silent mode Y Noise level 27.8 dB Bearing technology HDB Mean time between failures (MTBF) 120000 h Certification CE, UL, TÜV, FCC, CCC, EAC, S-Mark, BSMI Ports & interfaces Motherboard power connector 24-pin ATX Motherboard power cable length 60 cm Number of SATA power connectors 3 SATA power cable length 150,500 mm Peripheral (Molex) power connectors (4-pin) 4 Peripheral (Molex) power cable length 150,500 mm PCI Express power connectors (6-pin) 2 PCI Express power connectors (6+2 pin) 4 CPU power connector (4+4 pin) Y CPU power cable length 65 cm Floppy disk drive connector Y Floppy disk drive cable length 15 cm Cabling type Modular Packaging data Cables included AC, CPU, PCIe, Peripheral (Molex), SATA Design Product colour Black Fan diameter 12 cm Number of fans 1 fan(s) Fan location Top On/off switch Y Operational conditions Operating temperature (T-T) 5 - 50 °C Storage temperature (T-T) -40 - 55 °C Operating relative humidity (H-H) 20 - 85 % Storage relative humidity (H-H) 10 - 95 % Weight & dimensions Width 150 mm Depth 140 mm Height 86 mm
Power Total power 850 W Peak power 900 W AC input voltage 100 - 240 V AC input frequency 50/60 Hz Input current 10 A Power Factor Correction (PFC) type Active Combined power (+3.3V) 100 W Combined power (+12V) 744 W Combined power (-12V) 3.6 W Combined power (+5Vsb) 12.5 W Max output current (+3.3V) 20 A Max output current (+12V) 62 A Max output current (+5V) 20 A Max output current (-12V) 0.3 A Max output current (+5Vsb) 2.5 A Hold time 16 ms Power protection features Over current, Over voltage Performance Power supply unit (PSU) form factor ATX 80 PLUS certification 80 PLUS Platinum Silent mode Y Noise level 27.8 dB Bearing technology HDB Mean time between failures (MTBF) 120000 h Certification CE, UL, TÜV, FCC, CCC, EAC, S-Mark, BSMI Ports & interfaces Motherboard power connector 24-pin ATX Motherboard power cable length 60 cm Number of SATA power connectors 3 SATA power cable length 150,500 mm Peripheral (Molex) power connectors (4-pin) 4 Peripheral (Molex) power cable length 150,500 mm PCI Express power connectors (6-pin) 2 PCI Express power connectors (6+2 pin) 4 CPU power connector (4+4 pin) Y CPU power cable length 65 cm Floppy disk drive connector Y Floppy disk drive cable length 15 cm Cabling type Modular Packaging data Cables included AC, CPU, PCIe, Peripheral (Molex), SATA Design Product colour Black Fan diameter 12 cm Number of fans 1 fan(s) Fan location Top On/off switch Y Operational conditions Operating temperature (T-T) 5 - 50 °C Storage temperature (T-T) -40 - 55 °C Operating relative humidity (H-H) 20 - 85 % Storage relative humidity (H-H) 10 - 95 % Weight & dimensions Width 150 mm Depth 140 mm Height 86 mm
Caratteristiche
Brand:
Thermaltake
EAN:
4713227525404
Peso:
2.8
